| Pump Size |
60, 80, 110, 20, 30, 40, 50 |
| Displacement (cm3/rev) |
19 (FRM 20), 30.4 (FRM 60), 39.38 (FRM 40), 59.86 (FRM 60), 78.79 (FRM 80), 109.47 (FRM 110) |
| Maximum continous pressure (P1) (bar) |
250 |
| Maximum peak pressure (P3) (bar) |
300 |
| Speed (r.p.m) max. cont. |
2000 (FRM 20, 30, 40), 1700 (FRM 60), 1500 (FRM 80), 1400 (FRM 110) |
| Speed (r.p.m) max. int. |
2500 (FRM 20, 30, 40), 2200 (FRM 60), 2000 (FRM 80), 1800 (FRM 110) |
| Power kW cont. |
15 (FRM 20), 20 (FRM 30), 27 (FRM 40), 34 (FRM 60), 41 (FRM 80), 52 (FRM 110) |
| Power kW max. int. |
20 (FRM 20), 27 (FRM 30), 37 (FRM 40), 44 (FRM 60), 54 (FRM 80), 67 (FRM 110) |
| Output type |
A – SAE B – 13 tooth, B – SAE BB – 15 tooth, D – DIN 5462 8 Tooth Spline |
| Pump rotation |
L (Anti clockwise), R (Clockwise), Bi-directional |
